Specialised PCB Features & Technologies
At Wrekin Circuits, we offer a range of specialised features and technologies to enhance the functionality, durability, and customisation of your PCBs.
These advanced techniques allow us to meet the unique demands of complex designs and industry-specific requirements. Our specialized capabilities ensure that your PCBs perform optimally, even in the most demanding environments.
Technologies We Offer:
Depth Drill & Stacked Vias:
Precision drilling at controlled depths, combined with stacked vias, allows for reliable interconnections in multi-layer PCBs, optimizing space and improving signal integrity.
Edge Plating:
Countersinks & Counterbore:
Custom holes with countersinks (angled edges) and counterbores (flat-bottomed holes) are used to fit fasteners flush with the PCB surface, improving the aesthetic and mechanical integration in enclosure designs.
Alternative Solder Resist and Ident Colours:
We offer a variety of solder resist and ident (legend) colours, allowing for greater customization and differentiation of PCBs, ideal for branding or simplifying assembly processes.
Depth Control Milling:
Castellated Holes:
Castellated Holes are half-plated holes along the edges of the PCB that allow for easy soldering onto another PCB, commonly used for PCB modules or board-to-board connections.
Step Plating:
Step plating allows for varying copper thicknesses in different areas of the PCB. This is particularly useful for designs requiring thicker copper in high-current areas, while maintaining thinner copper in areas where it’s not needed, offering both flexibility and cost savings.
If you’d like to learn more about how these specialised technologies can enhance your PCB designs, contact us today! Speak to our expert technical team at Wrekin Circuits to discuss your project requirements in more detail and explore the best solutions for your application.
