PCB Types & Technologies We Manufacture in the UK

Wrekin Circuits manufactures the full range of printed circuit boards in Telford: from cost-effective single-sided boards to 36-layer multilayers, flexible and flex-rigid circuits, IMS and ceramic boards. Alongside them we offer advanced technologies such as heavy copper up to 24oz, controlled impedance, micro BGA and via-fill that let you push designs further. Every board is made in Britain and 100% electrically tested.

Our PCB Technologies:

At Wrekin Circuits, we offer a comprehensive array of PCB types and advanced manufacturing technologies, including:

Single-Sided PCBs

The most basic and cost-effective option, ideal for low-power, simple electronics where components are mounted on one side of the board.

Double-Sided PCBs

A versatile option with components on both sides, perfect for more complex circuits and medium-density designs.

Multilayer PCBs

With three or more layers of conductive material, our multilayer boards are perfect for high-density, high-performance designs where space-saving and advanced...

Flex PCBs

Designed to bend and conform to tight spaces, our flexible circuits are ideal for innovative and space-constrained applications such as wearable technology and consumer...

Flex-Rigid PCBs

Combining the durability of rigid boards with the adaptability of flexible circuits, our flex-rigid PCBs are perfect for complex designs requiring both flexibility and...

Via Fill Technology

Whether it's copper fill vias for enhanced thermal and electrical performance, or resin fill for improved surface planarity and mechanical strength, via fill technology...

Heavy Copper PCBs

For high-current, high-power applications, our heavy copper boards feature copper weights up to 24oz, providing superior heat dissipation and current-carrying capacity.

Impedance Control

With single-ended and differential impedance control, we ensure signal integrity and reduce electromagnetic interference, making your boards suitable for high-speed and...

Micro BGA

Our expertise in Micro BGA technology allows us to deliver compact, high-performance boards with precise connections, ideal for miniaturized, high-density designs.

Advanced Technologies at Wrekin Circuits:

To enhance the performance, reliability, and durability of your PCB designs, Wrekin Circuits offers advanced manufacturing techniques, such as:

Explore Our PCB Technologies

 For more details on the various PCB types and technologies we offer, check out our dedicated pages. Each page provides in-depth information on how our advanced technologies can enhance your projects.

$

Single-Sided PCBs

$

Multilayer PCBs

$

Flex-Rigid PCBs

Put us to the test. Whether you need a prototype tomorrow or a production partner for the next decade, talk to the team that has been making circuit boards in Britain for over 30 years.
